Description of Automatic 2000CPH 12 head 2 in 1 CO2 injection cans filling machine
DG Series Isobaric Filling Machine (Carbonated Beverage Filling Machine) is mainly used for filling carbonated beverages such as soft drinks, cola, sparkling wine, fruity water, etc. It has the characteristics of advanced structure, stable operation, safe operation, convenient maintenance, stepless speed regulation, and high production efficiency. It is an ideal carbonated beverage filling machine for small and medium-sized beverage factories.
Monoblock 2000CPH 12 head 2 in 1 Carbonated soft drink can filling machine:
It is used for filling and sealing for aluminum canned beer/CSD and also other cans; The cans can be connected with can washer with belt conveyor.
Characters of Sealer:
1, PLC control to make sure no can, no lid loading, no sealing and alarm on less lids; As well emergency stop under several lids on one can;
2, Energy saving model, one motor can process all actions;
3, Full sealing effect make sure to be suitable for liquid packing can;
4, The machine suitable for all kinds of cans with same diameter, height can be adjusted easily with one lifting hand wheel;
5, Compact construction, only need small space to use the machine;
6, Delivered with whole machine, no need commissioning again after delivery;
7, lid loading channel can hold more lids than old model can sealer, and it is outer set lid channel for more safety;
Parameters of the 2000CPH 12 head 2 in 1 Carbonated soft drink can filling machine:
Power: 4.5KW
Dimension: 1900*1500*2300mm
Weight: 3000kg
Pressure: max 0.4Mpa
Equipment list of the 2000CPH 12 head 2 in 1 Carbonated soft drink can filling machine:
| Items | Description | Model | Size(mm) | Qty. |
| 1.1 | Horizontal can washer | XG-1.5 | 1500*600*1500 | 1set |
| 1.2 | Monoblock beer can filler-sealer | DG12-1 | 1900*1500*2300 | 1set |
| 1.2.1 | 2m+2m conveyor+1motor | / | / | 1set |
| 1.3 | Ink jet code printer | OH-338 | 347*220*100 | 1set |
| 1.3.1 | Reverse units | Turn over and not come back | 1pc |
