Description of Monoblock auto 2 in 1 12-4 Open-Air juice cans filling machine
It is used for filling and sealing for liquid without gas / pressure packed in cans and also other cans; The cans can be connected with can washer with belt conveyor. We can also supply the can labeling machine, can date printer, can packing machine.
12 head can filling:
1) All liquid touching parts are made of SUS304
2) The pressure mechanical valve is introduced the advanced foreign design with a fast filling speed, no hygiene corner pocket, a few sealing parts, and precise liquid level control. The whole valve is made of 304 stainless steel.
3) The filling valve opens and begins filling when it moves down and touches the can neck, the filling valve move up and leave the bottleneck when it finishes filling.
4) The liquid supply adopts the automatic pneumatic valve magnetic liquid-level switch to control the liquid tank automatically.
5) The motivation of the filler is derived from the driven system in the framework and passed by gear.
4 heads can sealing:
1, Ingenious lid loading device to make sure no can, no lid loading, no sealing;
2, Energy saving model, one motor can process all actions;
3, Full sealing effect make sure to be suitable for liquid packing can;
4, The machine suitable for all kinds of cans with same diameter, height can be adjusted easily;
5, Twice sealing tech to make well sealing effect, no leakage;
6, The sealing chunk-rolls from TAIWAN, Sealing wheel life time can reach 5 million times
7, Easy adjusting wheel for changing different height cans very easy
Parameters of Monoblock auto 3000CPH 2 in 1 12-4 Open-Air can filling machine:
Power: 4.5KW
Dimension: 2100*1800*2000mm
Weight: 4000kg
Pressure: max 0.4Mpa
Equipment list of Monoblock auto 3000CPH 2 in 1 12-4 Open-Air can filling machine:
| Items | Name of machine | Model | Size(mm) | Qty. |
| 1.1 | Monoblock juice can filler-sealer | CGF12-4A | 2100*1800*2000 | 1set |
| 1.1.1 | Inlet belt conveyor | SYS-1 | / | 2m |
| 1.1.2 | Outlet belt conveyor | SYS-1 | / | 2m |
4 sealing heads:
Touch control screen:
